Tension Sleeve Safety Joint Frac RTTS Safety Joint For DST Drill Stem Test Equipment

  • 1
  • 2

Brand Name : ZZ TOP OIL TOOLS

Model Number : RTTS Safety Joint

Certification : ISO, API

Place of Origin : China

MOQ : 1 set

Price : USD 1-10000/set

Payment Terms : L/C, T/T, D/P

Supply Ability : 10 set/month

Delivery Time : 30-50 days

Packaging Details : Pollywood

Product : RTTS Safety Joint

Type : APR Tools

Size : 5 1/2 inch

Working Pressure : 10000psi

Application : Oil Well Downhole Testing Service

Connection : IF, EUE , CAS

Working Condition : Oil & Gas & H2S service

Working Temperature : Up to 425oF

Contact Now

Tension Sleeve Safety Joint RTTS Safety Joint For DST Service
The Tension Sleeve Safety Joint is the full bore RTTS Tools used in oil well downhole testing service, fracturing and cementing operation. The RTTS safety joint is used with RTTS packer during operation, as an optional tool that aids in removal of the workstring if the packer becomes stuck (cemented in, stuck in collapsed casing, etc.). To initiate the release of the safety joint, part a tension sleeve by pulling on the workstring with enough overpull to shear the tension sleeve.


Technical parameter of Tension Sleeve RTTS Safety Joint

Nominal Size4 1/2-5”5 1/2-6 5/8”7-7 5/8”8 5/8-20”
OD93.5mm103.1mm127.5mm155.5mm
ID48mm50.8mm62mm79mm
Length1033.4mm1083.7mm1160mm1195.5mm
Working Pressure70Mpa(10000psi)
Tensile Strength650KN902KN1059KN2273KN
Burst Pressure120.9Mpa194.6Mpa115Mpa142Mpa
Collapse Pressure103.3Mpa140.2Mpa109Mpa116Mpa
Torque Strength8.1kN.m12kN.m27kN.m45.5kN.m
Working Temp.-29oC~180oC
ServiceH2S NACE MR0175(Above 175F)
Connection ThreadEUE/IF/CAS


Tension Sleeve Safety Joint Frac RTTS Safety Joint For DST Drill Stem Test Equipment Tension Sleeve Safety Joint Frac RTTS Safety Joint For DST Drill Stem Test Equipment
