Oil Well Production Packer HP Hydraulic Set Retrievable Packer 7" X 15000psi

Name: Oil Well Production Packer HP Hydraulic Set Retrievable Packer 7quot X 15000psi
Brand: ZZ TOP OIL TOOLS
Price: 1 USD

Quality Oil Well Production Packer HP Hydraulic Set Retrievable Packer 7" X 15000psi wholesale

Brand Name : ZZ TOP OIL TOOLS

Model Number : HP Retrievable Packer

Certification : ISO, API

Place of Origin : China

MOQ : 1 set

Price : USD 1-10000/set

Payment Terms : L/C, T/T, D/P

Supply Ability : 10 set/month

Delivery Time : 30-50 days

Packaging Details : Pollywood

Product : Hydraulic- set Retrievable Packer

Material : AISI 4130 Alloy Steel

Casing Size : 7"

Working Pressure : 15000 Psi

Connection : CAS, EUE, IF

Usage : Oil Well Production

Working Condition : Oil & Gas H2S service

Working Temperature : 300oF

Contact Now

Oil Well Production Packer HP Hydraulic Set Retrievable Packer 7" x 15000psi

The HP retrievable packers with hydraulic setting is used in oil well production service. The HP retrievable packer is a rubst and cost effective packer, which is designed with the performance of a permanent packer and combine the pressure and ratings. The HP retrievable packer featured with the convenience of operation without the expensive seal units required in more demanding applications. The differential pressures HP retrievable packer is up to 15,000 psi and the temperature is up to 400°F .

The HP hydraulic-setting retrievable packer can be used in hot, corrosive and deviated well production job or test completions, single trip completions, multi-packer installations and the wells where minimum casing deformation or damage is desired

Technical Parameter of Hydraulic-set HP retrievable packer

Casing Size	Casing Weight	Max.OD	Min.ID
in.	lb/ft	in	in
7	26-32	5.92	3.80
	29-32	5.92	3.72
	29-32	5.92	3.88
	32-35	5.82	3.72
7 5/8	47.1	6.125	3.32
8 5/8	57.4	7.125	3.32
8 5/8	61.4	6.935	3.32

* The Hydraulic-set Retrievable Packer are interchangeable with Halliburton's Packer.

Oil Well Production Packer HP Hydraulic Set Retrievable Packer 7" X 15000psi

Product Tags:

Oil Well Production Packer HP Hydraulic Set Retrievable Packer 7" X 15000psi Images
